Connector 2pins big

Plug for voltage supply

  • Connector socket with 2 contacts
  • Cable connection with screw terminal
  • Locked with the jack with screws

docu / downloads
applications

Technical data


Number of positions: 2
Nominal voltage: 250 V (maximum)
Nominal current: 12 A (maximum)
Pitch: 5,08 mm
Stripping length: 7 mm
Inflammability class: V0
Scope of delivery:
Power connector 2pins big
Commercial data:
EAN number: 4260363240970
HS-code: 85366990
Weight: 0.0100 kg
applications technical data Cart
ARTNR #
Summe: 0,-

technical data
applications
docu / downloads

article:
Art. ID.name
9371-24 Power connector 2pins big
connector plug lockable by jack with screws
